LRP-style relevance propagation for the real-valued (+, x) provenance-semiring Datalog circuit built in Mission 1/2 – Phase 3 Mission 3 of campaign_exai_dl_library_neuro_symbolic (LRP for the Datalog/Provenance-Semiring Circuit), extending Phase 1-2's fuzzy-logic LRP methodology (the weighted-sum/ epsilon-rule split for +, the bilinear split for x) to derived-fact weights instead of Module output tensors.
More...
Go to the source code of this file.
|
| struct | pulsatrix::datalog::RelevanceResult |
| | The result of one propagate_relevance_weighted call: relevance recorded at every atom the recursion visited (all_atoms, useful for inspection/debugging), and relevance recorded only at atoms with zero matching derivations in fixpoint – the extensional/base facts (base_facts) – which is what an end-to-end conservation check must sum against the seeded relevance, per ordinary LRP convention (intermediate/derived atoms are redistribution waypoints, not part of the conserved total, exactly as an ordinary Module chain's intermediate activations are not summed alongside its raw inputs). More...
|
| |
|
| RelevanceResult | pulsatrix::datalog::propagate_relevance_weighted (const std::vector< Rule > &rules, const WeightedFactDatabase< double > &fixpoint, const Atom &query, double relevance_seed, double epsilon=1e-6) |
| | Propagates relevance from query's derived weight back through every derivation path in fixpoint (a stable, already-evaluated naive_evaluate_weighted< RealSemiring<double>> result), down to every extensional/base fact that contributed to it – see this file's header doc comment for the full hand-derived rule and worked numeric example.
|
| |
LRP-style relevance propagation for the real-valued (+, x) provenance-semiring Datalog circuit built in Mission 1/2 – Phase 3 Mission 3 of campaign_exai_dl_library_neuro_symbolic (LRP for the Datalog/Provenance-Semiring Circuit), extending Phase 1-2's fuzzy-logic LRP methodology (the weighted-sum/ epsilon-rule split for +, the bilinear split for x) to derived-fact weights instead of Module output tensors.
- Note
- Hand-derived rule (Stage 3 design question 1), worked before implementation, on Mission 1's diamond-graph toy program: a derived fact's weight is a
⊕-sum of ⊗-products over derivation paths – e.g. ancestor(a,d) = edge(a,b)*ancestor(b,d) + edge(a,c)*ancestor(c,d), and (in this specific toy KB, since b/c each have exactly one outgoing edge) ancestor(b,d) = edge(b,d), ancestor(c,d) = edge(c,d) – so ancestor(a,d) = edge(a,b)*edge(b,d) + edge(a,c)*edge(c,d). This is structurally identical to the (+, x) circuit shape Phase 1-2 already derived LRP rules for (ConjunctionModule's Product-t-norm bilinear split for x, LinearModule's epsilon-rule weighted-sum split for +) – the rule below is that exact composition, reapplied one level at a time down the Datalog derivation DAG rather than down a Module chain, recursing at any body position that is itself a derived (non- extensional) atom, rather than assumed to generalize trivially from the single-path case without being re-derived for this specific multi-path circuit shape:
- **
⊕ level (weighted-sum/epsilon-rule split across derivation paths).** If atom h's fixpoint weight is y = sum_k z_k (over every (rule, substitution) match k deriving h, z_k that match's ⊗-product weight), relevance R_h arriving at h splits across matches as R_k = (z_k / (y + eps*sign(y))) * R_h – exactly LinearModule::propagate_relevance's own epsilon rule, applied to derivation-path terms instead of a linear layer's summands.
- **
x level (bilinear split across a match's body atoms).** Within match k, z_k = x_1 * x_2 for a two-atom rule body (every rule body in this campaign's toy programs has arity 1 or 2 – see the arity-2 restriction note below), so R_k splits via ConjunctionModule's own Product-t-norm bilinear rule: contribution = (x_1*x_2 / (2*z_k + eps*sign(z_k))) * R_k, given to both x_1 and x_2 (near-exactly R_k/2 each, exactly R_k/2 each at eps=0, since x_1*x_2 == z_k makes the fraction z_k/(2*z_k) = 1/2 identically regardless of the actual operand values). A one-atom body (Mission 0's base rule, ancestor(X,Y):-edge(X,Y).) is a trivial one-factor "product" – z_k already equals that single factor, so it is a pass-through, not a new case: R_k flows to the one body atom unchanged, mirroring NegationModule/ReluModule's own single-input pass-through precedent (Phase 2 Mission 0's Sigmoid Design Decision note makes the same move for exactly this reason).
- Recursion, not a one-level formula. If a body position's grounded atom is itself a derived (non-extensional) fact – e.g.
ancestor(b,d) at the recursive rule's Z=b match – the relevance it receives from step 2 becomes its own R_h for another application of steps 1-2 against its derivations, recursing until every relevance-bearing quantity has been pushed back to an atom with zero matching derivations in the fixpoint database (an extensional/base fact – e.g. edge(b,d), never the head of any rule in this campaign's toy programs). This is the piece a naive "just apply the single-path formula" reading of Decision Point 2's rationale would have missed: ancestor(a,d)'s own two paths are NOT both flat products of four base facts in general – only in this specific toy KB do they happen to collapse to that shape, because ancestor(b,d)/ancestor(c,d) are themselves single-path-derived from a base fact one level down. A KB where b/c have their own multi-path onward routes would need this same rule applied recursively at that next level too, which this implementation does unconditionally (not special-cased to a fixed depth of two).
- Note
- Hand-worked numeric check (Mission 1's diamond KB, constant weights,
edge(a,b)=0.5, edge(a,c)=0.4, edge(b,d)=0.6, edge(c,d)=0.3, seed R=1.0 at ancestor(a,d), eps=0 for exactness): ancestor(a,d) derivations: path1 (Z=b) weight=0.5*0.6=0.30, path2 (Z=c) weight=0.4*0.3=0.12 total = 0.42 (matches the fixpoint weight) R_path1 = 0.30/0.42 = 0.714286 R_path2 = 0.12/0.42 = 0.285714 (sum = 1.0) path1 bilinear split (edge(a,b)=0.5, ancestor(b,d)=0.6): each gets R_path1/2 = 0.357143 (a 2-term product's bilinear split is always exactly half-and-half at eps=0, independent of the operand values, since x1*x2/(2*x1*x2) == 1/2 identically) recurse into ancestor(b,d), r_out=0.357143: single derivation (edge(b,d)=0.6, arity 1) -> pass-through, edge(b,d) receives 0.357143 path2 bilinear split (edge(a,c)=0.4, ancestor(c,d)=0.3): each gets R_path2/2 = 0.142857 recurse into ancestor(c,d), r_out=0.142857: single derivation (edge(c,d)=0.3, arity 1) -> pass-through, edge(c,d) receives 0.142857 Leaf relevances: edge(a,b)=0.357143, edge(b,d)=0.357143, edge(a,c)=0.142857, edge(c,d)=0.142857 Sum = 1.0 == seed, exactly (eps=0) -- verified by DatalogLRPTest.MultiPathDiamondFactConservesRelevanceMatchingHandDerivedSplit. And the single-path boundary case, ancestor(a,b) (derivable only directly from edge(a,b), arity-1 body): R_out flows entirely, unsplit, to edge(a,b) – verified by DatalogLRPTest.SinglePathFactReceivesEntireRelevanceNoSplit.
-
Scope restriction, deliberate and logged: rule bodies of arity > 2 throw
std::logic_error rather than silently approximating an n-ary bilinear split – no toy program in Missions 0-3 has a rule body wider than two atoms (the recursive ancestor rule's body is always exactly edge(X,Z), ancestor(Z,Y)), so this generalization is genuinely undesigned-for rather than assumed-fine, per this project's "log the honest boundary, don't silently extend past what's been derived" convention (mirrors datalog_weighted_engine.cpp's own logged extensional-and-rule-head scope note).
-
Acyclic-derivation-DAG assumption, deliberate and logged: this function recurses down the fixpoint's own derivation structure with no cycle/memoization guard. Every toy program in this campaign (
ancestor over a DAG of edge facts) has an acyclic derivation graph by construction (a transitive-closure relation over a finite DAG cannot derive an atom from itself), so this is not exercised as a defect here, but a Datalog program whose derivation graph (not just its underlying fact graph) contains a genuine cycle would recurse unboundedly – flagged here rather than silently assumed safe in general, mirroring Mission 0's own empty-body-rule scope note convention.
